TECHNICAL SPECIFICATIONS
Features
| Channels | 2 |
| UHC-MOS single push pull circuit | Yes (Advanced) |
| LC mounted twin transformer | Yes |
| Wide range amplifier | Yes |
| High current dynamic power supply | Yes |
| Power amp discrete construction | Yes |
| Micro processor auto off | Yes |
| Solid Heat Sinks | Yes (Separate) |
| Source Direct | Yes |
| Balance / Bass / Treble / Loudness | Yes / Yes / Yes / No |
| Digital in: USB-B / optical / coaxial / USB-A | Yes / 2 / 1 / No |
| Sample Rate digital In | 192 kHz / 24-bit |
| USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 | 11.2 |
| USB-B PCM sample rate | 384 kHz / 32-bit |
| DAC chip | PCM1795 |
| Asynchronous mode rear USB | Yes |
| Bit-perfect transmission | Yes |
| AL 32 Processing | Advanced AL32 Plus |
| DAC Master Clock Design | Yes |
| Streaming audio from PC | Yes |
| Analogue Mode | Yes |
Inputs Outputs
| Audio Inputs | 4 |
| Phono Input: MM / MC | Yes / Yes |
| Audio Outputs | 1 |
| Gold plated Cinch | Yes |
| Number of terminals | 2 |
| Remote Control Bus in / out | Yes |
| Headphone Out | Yes |
| Digital in: USB-B / optical / coaxial / USB-A | Yes / 2 / 1 / No |
Specifications
| Output power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07%) | 70 W |
| Output power 4 Ohm (1 kHz, T.H.D. 0.7%) | 140 W |
| Total Harmonic Distortion | 0.01% |
| Input Sensitivity: MM | 2.5 mV / 47 kohm |
| Input Sensitivity: MC | 200 uV / 100 ohm |
| Signal to Noise Ratio: MM/MC | 89 dB / 74 dB |
| Input Sensitivity: High level | 125 mV / 47 kohms |
| Signal to Noise Ratio: High level | 108dB |
| Treble Control | ± 8 dB at 10 kHz |
| Bass Control | ± 8 dB at 100 Hz |
General
| Available colors: Premium Silver / Black | Yes / Yes |
| Metal Front Panel | Yes |
| Power Consumption in W | 295 |
| Standby Consumption in W | 0.2 |
| Auto Power Off | Yes |
| Detachable Power Cable | Yes |
| Remote Control | RC-1213 |
| System Remote Function | Yes |
| Maximum Dimensions (W x D x H) in mm | 434 x 414 x 135 |
| Weight in kg | 17.6 |
