P3LED full color
Pixel composition: 1R1G1B
Brightness: ≥500cd/㎡
Pixel pitch: 3mm
111111 pixels/square meter
Module size: 192*192mm,
Module resolution: 64*64 points
Maximum power consumption: 800W/square meter
Average power consumption: 400W/square meter
Refresh frequency: above 1920HZ
LED light model: SMD2121
.jpeg)
(1).jpeg)
Display module parameters
Module size: 192*192
Module resolution: 64*64
Lamp bead model: SMD2121
Structural requirements: Maintenance before magnetic suction
Lamp bead model: SMD2121
Structural requirements: Maintenance before magnetic suction
Pixel pitch/pixel density: 3mm/ 111111 dots/m2
Pixel composition 1R1G1B
Scanning method 1/32 scan
Screen brightness ≥ 500cd/M²
Maximum and typical power consumption 800W/m2 400W/m2
Viewing angle ≥160° horizontally, 140° vertically
Grayscale: red, green, and blue 16-bit coding
Correction technology: equipped with single-point brightness, chromaticity correction technology and whole-screen brightness correction technology
Brightness adjustment: Automatically adjust 16 levels according to the ambient brightness, manual and program adjustment 100% level
Image adjustment: brightness, contrast, grayscale correction coefficient, color range adjustment, etc.
Main control system Mosier
Best viewing distance ≥3m-100m
Frame changing frequency ≥60Hz
Refresh frequency ≥1920Hz
Input voltage AC110-AC220V/60HZ
Control method synchronous control
Drive mode: constant current drive
LED life 100000 hours
Mean time between failures 10,000 hours
Light decay ﹤3%
Screen flatness ±0.5mm/m2
Protection grade IP25
Electrical protection: overcurrent, short circuit, open circuit, overvoltage, undervoltage
Environmental requirements Working temperature: -20℃ ~ +60℃; Relative humidity: 10% ~ 90RH%
