Details

---

Features:
▼ 16 channels of analog balanced input interfaces and 8 channels of analog balanced
output interfaces.
▼ Equipped with 4 AES/EBU output channels.
▼ 16 XLR input channels with 8-level sensitivity adjustment, providing 48V phantom
power, noise gate, compressor, and phase functions.
▼ 3-position switch + 3 green LED lights to set a unique ID (1-3) for the stage box.
▼ Uses PT40 switching power module, AC100-240V (50/60Hz), with power switch control
and indicator lights on the front panel.
▼ By using the DANTE protocol, our LM40 and LM48 mixing consoles can be integrated
and connected with the stage box.
▼ Supports cross-platform APP, available to control of the stage box through the main
console.
▼ 2U standard stage box, available for rack installation.
▼ Constructed with high-quality components to ensure long-lasting durability.
